LED Adjustable Wall Pack | 12K Lm Max | 120/277V | CCT Selectable | WPASR

The WPASR Adjustable Wall Pack – Sensor Ready – Selectable CCT & Lumen is a high-performance commercial outdoor lighting solution engineered for building exteriors, warehouses, parking areas, walkways, loading docks, security lighting, and industrial facilities. Designed for flexibility and durability, this adjustable LED wall pack combines field-selectable color temperatures, selectable lumen output, integrated energy-saving controls, and rugged commercial-grade construction.

Built for both retrofit and new construction applications, the WPASR series features selectable 3000K, 4000K, and 5000K color temperatures, allowing contractors and facility managers to customize light appearance based on the environment. Use 3000K warm white for softer exterior lighting, 4000K neutral white for balanced visibility, or 5000K cool white for high-security and high-visibility applications.

The WPASR family delivers flexible lumen packages ranging from 2,739 to 11,875 lumens, depending on the selected model. The WPASR-6543L-3CCT provides 2,739 to 6,002 lumens, while the WPASR-121086L-3CCT delivers 6,402 to 11,875 lumens. Combined with an adjustable housing capable of aiming up to 90°, this fixture allows precise light distribution for entrances, perimeter walls, pathways, service areas, and commercial exteriors.

Constructed with a rugged die-cast aluminum housing and finished in a durable bronze powder coat, the WPASR wall pack is built to withstand harsh outdoor conditions. The durable polycarbonate lens enhances optical performance while providing impact resistance. Rated IP65 for ingress protection and IK08 for impact resistance, this fixture is designed for demanding commercial and industrial environments.

The WPASR series operates on 120-277V universal voltage and includes standard 0-10V dimming capability for compatibility with modern lighting controls. A built-in switchable photocell is included for automatic dusk-to-dawn operation, while the sensor-ready screw-in design allows optional occupancy sensor integration for additional energy savings. Remote control functionality is available for sensor programming and adjustment.

Designed for long-term reliability, the fixture delivers up to 167,000 hours L70 and 51,000 hours L90 LED life, reducing maintenance costs and fixture replacements over time. Additional electrical features include 6kV surge protection, power factor above 0.9, and THD below 20% for efficient operation. Optional 4W or 8W emergency drivers are available for enhanced safety and emergency lighting applications.

The WPASR Adjustable Wall Pack is DLC Premium listed, cULus wet location rated, FCC compliant, and ideal for commercial buildings, distribution centers, industrial facilities, parking structures, and outdoor security lighting projects requiring customizable and energy-efficient illumination.

Technical Specifications

Product Type: Adjustable LED Wall Pack
Series: WPASR Sensor Ready Adjustable Wall Pack

Optical System

• Selectable CCT: 3000K / 4000K / 5000K
• WPASR-6543L-3CCT Lumens: 2,739 – 6,002 lm
• WPASR-121086L-3CCT Lumens: 6,402 – 11,875 lm
• CRI: >80
• Adjustable Housing: Up to 90°
• Lens Material: Polycarbonate
• LED Chromaticity: <6-step ANSI quadrangles
• Color Maintenance: < -0.0031 chromaticity shift (Δu’v’) over first 6,000 hours

Electrical

• Voltage: 120-277V
• Frequency: 50/60Hz
• Dimming: 0-10V DC
• Photocell: Integrated switchable photocell
• Sensor Ready: Screw-in occupancy sensor ready
• Surge Protection: 6kV
• Power Factor: >0.9
• THD: <20%

Construction

• Housing Material: Die-Cast Aluminum
• Finish: Bronze Powder Coat
• Mounting: Wall Mounting Kit Included

Environmental

• Operating Temperature: -40°F to 122°F
• Wet Location Rated
• IP Rating: IP65
• Impact Rating: IK08
• cULus Listed
• DLC Premium Listed
• FCC Part 15 Class A Compliant

Lifespan & Options

• L70 Lifetime: 167,000 Hours
• L90 Lifetime: 51,000 Hours
• Optional Emergency Drivers: 4W or 8W
