Low Profile Weatherproof Cover | Single Mounting Bracket | Vertical/Horizontal Mount | WP6000

Protect outdoor receptacles with the slim and functional Low-Profile Weather Resistant Plastic Cover (WP6000 Series). Featuring a compact 1.5-inch depth profile, this single-gang cover offers sleek protection against weather elements while maintaining a low-profile footprint on exterior walls. Built for efficiency, it features NEW faster installation pre-programmed for GFCI receptacles with no inserts required out of the box, while still including mounting screws, base, cover assembly, gasket, and adapter inserts for versatile field configurations.

Constructed from heavy-duty, UV-stabilized polycarbonate, the WP6000 series includes a 100% paintable surface to easily match any residential or commercial building aesthetic. It complies with 2020 NEC Section 314.15 for wet locations and holds cULus Certification for Type 3R outdoor enclosures. Engineered for reliable outdoor performance, it passes extreme cold-impact testing down to -60°F (-51°C), withstands a 12 lbf. impact test, and utilizes a reinforced hinge pin for long-term reliability.

Security and environmental sealing are built into every unit: it features a 1/8" (3 mm) thick neoprene gasket with screw slots and an integrated lockable hasp accepting padlocks with up to a 0.19" (4.8 mm) shank diameter. The low-profile cavity accommodates standard cords up to 1x16 AWG.

Key Features:

• Ultra-Slim 1.5" Depth Profile: Streamlined low-profile enclosure reduces exterior wall protrusion while protecting connected cords.

• Pre-Programmed GFCI Setup: Features faster installation pre-configured for GFCI devices without requiring inserts out of the package.

• 100% Paintable Surface: High-impact UV-stabilized polycarbonate body can be painted to match any building finish.

• Universal Vertical/Horizontal Mounting: Flexible hinge and base system supports both vertical and horizontal single-gang installations.

• Weather-Sealed & Code Compliant: UL Type 3R rated, NEC 314.15 wet location compliant, cold-impact rated down to -60°F, and backed by a 1-year limited warranty.

Technical Specification Table

Product Logic & Ordering Catalog Matrix

Packaging & Included Hardware

• Package Contents:

  • Single-Gang Low-Profile Polycarbonate Cover and Base Assembly.

  • 1/8" (3 mm) Thick Neoprene Sealing Gasket.

  • Multi-Receptacle Adaptor Inserts (Pre-configured for GFCI).

  • Mounting Screws & Hardware.

• Carton & Shipping Specifications:

  • Unit Carton Dimensions: 3.7" W x 5.5" L x 1.5" H

  • Unit Carton Weight: 0.35 lbs

  • Pallet Quantity: 2,400 Units
