The LR42626 (White) and LR42627 (Black) Architectural Linkable Linear V60° Connectors are precision-designed accessories engineered to expand the versatility of the Architectural Linkable Linear lighting system. These V60° connectors allow smooth angled transitions, enabling designers and contractors to create dynamic layouts including zig-zag, geometric, perimeter, and custom architectural lighting configurations.

Built for seamless integration with the existing linear series, these connectors maintain system-wide compatibility with 3CCT selectable (3500K / 4000K / 5000K) and 3-wattage selectable linear fixtures. With a 120° beam angle, CRI 80, and high-performance photometric consistency, they ensure continuous uniform illumination across connected runs.

Each connector supports 0–10V dimming, operates on 120–277V, and is rated for 50,000 hours, ensuring reliable long-term performance. Available in White (LR42626) and Black (LR42627), they complement any modern commercial or architectural interior design.

📌 KEY TECHNICAL SPECIFICATIONS

General

• Models: LR42626 (White), LR42627 (Black)

• Description: ARCHL-V60/3CCT/3WO/WT and ARCHL-V60/3CCT/3WO/BK

• Shape: Architectural Linear

• Finish: White or Black

Photometric

• CCT Selectable: 3500K / 4000K / 5000K

• Beam Angle: 120°

• CRI: 80

Electrical

• Input Voltage: 120–277V

• Dimming: 0–10V

• Rated Lifetime: 50,000 hours

• Power Factor: 0.9

• Operating Temperature: –4°F to 113°F

Packaging

LR42626 – White

• UPC: 793888481046

• Master Barcode: 10793888481043

• Master Carton: 17.40" × 15.11" × 17.12"

• Case Size: 20

LR42627 – Black

• UPC: 793888481145

• Master Barcode: 10793888481142

• Master Carton: 17.40" × 15.11" × 17.12"

• Case Size: 20
