The LR42615 (White) and LR42616 (Black) Architectural Linkable Linear LED fixtures deliver high-performance, energy-efficient illumination for modern commercial and architectural spaces. Engineered for precision and design flexibility, each 8' linear luminaire features 3 CCT selectable options (3500K / 4000K / 5000K), three wattage levels (50W / 64W / 80W), and an advanced up/down lighting distribution system that enhances ambiance while supporting both task and general lighting needs.

These ultra-slim 1.97" wide linear fixtures provide powerful output ranging from 5750 to 9200 lumens, making them ideal for offices, educational facilities, conference rooms, retail environments, and large open spaces where seamless, continuous-row lighting is required. Designed with linkable architecture, they allow easy creation of long, uninterrupted lighting runs.

With a beam angle of 120°, CRI 80, high 115 lm/W efficacy, and a long-lasting 50,000-hour rated lifetime, the LR42615 and LR42616 combine visual comfort with reduced energy consumption. The fixtures support 0–10V dimming, operate on 120–277V, and are built to perform reliably in temperatures from –4°F to 113°F.

Both models—available in White and Black finishes—offer a clean architectural design that complements contemporary interiors while delivering professional-grade lighting performance.

📌 KEY TECHNICAL SPECIFICATIONS

General

• Model Numbers: LR42615 (White), LR42616 (Black)

• Description: ARCHL96/3CCT/3WO/WT/UPDN and ARCHL96/3CCT/3WO/BK/UPDN

• Size: 8 ft

• Shape: Architectural Linear

• Finish: White or Black

• Dimensions: 96.06" L × 1.97" W × 3.11" H

• MOL: 96.06"

Photometric

• CCT Selectable: 3500K / 4000K / 5000K

• Lumen Output: 5750 / 7360 / 9200 lumens

• Beam Angle: 120°

• CRI: 80

• Efficacy: 115 lm/W

• Light Distribution: Up/Down selectable

Electrical

• Wattage Options: 50W / 64W / 80W

• Input Voltage: 120–277V

• Dimming: 0–10V

• Power Factor: 0.9

• Rated Lifetime: 50,000 hours

• Yearly Energy Cost: $9.63

• Operating Temperature: –4°F to 113°F

Packaging

LR42615 – White

• UPC: 793888441644

• Master Carton: 10793888441641

• Dimensions: 98.4" × 7.32" × 8.07"

• Case Size: 6

LR42616 – Black

• UPC: 793888441743

• Master Carton: 10793888441740

• Dimensions: 98.4" × 7.32" × 8.07"

• Case Size: 6
