12 Inch Up-Down HO Outdoor Wall Sconce | 40W Max | 4.000Lm Max | 3-CCT Selectable | 120/277V

Illuminate your building exteriors with the LR40347 12" Up-Down High Output Outdoor Wall Sconce, finished in sleek black. Designed with a modern cylindrical wall profile, this LED fixture delivers powerful up-and-down lighting, ideal for residential, commercial, and hospitality applications. Perfect for entryways, patios, walkways, and architectural feature walls, it combines bold design with high-performance illumination.

Featuring CCT and wattage selectable technology, this wall sconce allows selection of 3000K, 4000K, or 5000K color temperatures and 20W, 30W, or 40W power levels, providing 2000–4000 lumens for bright, high-output lighting. Its 30° beam angle and CRI of 80 ensure uniform, high-quality illumination for accent, task, or ambient applications.

Operating on 120–277V with dual dimming capability (TRIAC @120V / 0–10V @120–277V), the LR40347 offers a 50,000-hour rated lifetime, 80 lm/W efficacy, and 0.9 power factor. It functions reliably in temperatures ranging from –4°F to 113°F, with an estimated yearly energy cost of $4.81. Each unit ships with complete UPC and master barcode details for easy inventory management.

🔧 Technical Specifications

Physical Dimensions

• Size: 12"

• Length: 12"

• Width: 4.72"

• Depth: 7.28"

• Shape: Outdoor Wall Sconce

• Finish: Black

• MOL: 12"

Photometric & Electrical

• Lumen Output: 2000 / 3000 / 4000

• Beam Angle: 30°

• CRI: 80

• CCT Options: 3000K / 4000K / 5000K

• Power: 20W / 30W / 40W

• Voltage: 120–277V

• Rated Lifetime: 50,000 hours

• Lumen Efficacy: 80 lm/W

• Power Factor: 0.9

• Frequency: 50/60Hz

• Dimmable: TRIAC @120V / 0–10V @120–277V

• Operating Temperature: –4°F to 113°F

• Estimated Yearly Energy Cost: $4.81

Packaging

• UPC Barcode: 793888420243

• Master Barcode: 10793888420240

• Master Carton Dimensions: 16.14" L × 16.02" W × 13.77" H

• Master Carton Weight: 27.89 lbs

• Case Size: 6
