The LR24166 2x4 LED Frame Panel is a versatile, energy-efficient lighting solution engineered for commercial, office, educational, and retail spaces. This high-performance panel features 5 CCT selectable color temperatures (3000K, 3500K, 4000K, 5000K, 6500K) and 3 wattage options (40W, 50W, 60W), enabling precise control over light output and color to meet any interior lighting requirement.

Measuring 47.7" x 23.7" with a slim 0.5" profile, the panel fits seamlessly into ceiling grids or surface mount installations. Its high CRI of 80 ensures accurate color rendering, and the wide 120° beam angle delivers uniform, glare-free illumination. Compatible with 0–10V dimming systems, the LR24166 offers a long operational life of 50,000 hours and reliable performance in temperatures ranging from -4ºF to 113ºF.

Constructed with a white finish, the LR24166 is ideal for offices, classrooms, conference rooms, and other commercial spaces requiring customizable, high-quality LED lighting.

⭐ Technical Specifications

• Item Number: LR24166

• Item Description: LED2X4FRAME/PNL/3WO/5CCT/D

• Size: 2x4

• Shape: Frame Panel

• Finish: White

• Dimensions:

  • Length: 47.7"

  • Width: 23.7"

  • Height: 0.5"

• Photometric:

  • Color Temperature: CCT Selectable (3000K / 3500K / 4000K / 5000K / 6500K)

  • Lumen Output: 5200 / 6500 / 7800 lm

  • Beam Angle: 120°

  • CRI: 80

• Electrical:

  • Power: 40 / 50 / 60 W

  • Input Voltage: 100–277V

  • Rated Lifetime: 50,000 hours

  • Dimmable: 0–10V

  • Power Factor: >0.95

  • Input Current: 0.67A Max

  • Frequency: 50/60Hz

  • Lumen Efficacy: 130 lm/W

  • Operating Temp: -4ºF to 113ºF

• Packaging:

  • UPC Barcode: 793888418745

  • Master Barcode: 10793888418742

  • Master Carton Dimensions: 50" x 24.40" x 8.07"

  • Weight: 20.94 lbs

  • Case Size: 6
