6" Square Slim Fire Rated LED Downlight | 1.600Lm | 120/277V | CCT Selectable | Goodlite G-97024

The 6” Fire-Rated Square Flush Slim LED Downlight is a high-performance, code-compliant lighting solution designed for applications requiring enhanced fire protection without compromising aesthetics. Featuring a trimmed square design and ultra-slim profile, this fixture delivers powerful illumination while maintaining a clean, modern ceiling appearance.

Engineered for demanding commercial and residential environments, this downlight is 2-hour fire rated and certified to UL 263 and ASTM E119, helping maintain ceiling fire integrity in multi-story buildings. The fixture is also IC rated, allowing direct contact with insulation for flexible installation.

With an efficient 18W LED producing up to 1600 lumens, this downlight delivers bright, uniform illumination with a wide 100° beam angle and CRI greater than 90 for excellent color accuracy. The integrated 5CCT selectable switch allows easy adjustment between 2700K, 3000K, 3500K, 4100K, and 5000K, making it adaptable to a wide range of spaces and lighting requirements.

Designed for versatility, the fixture operates on 120–277V and supports Triac or 0–10V dimming, ensuring smooth compatibility with residential and commercial dimming systems. The clip-in mounting system, compatible with double 5/8” sheetrock, enables fast and secure installation.

Rated for wet locations and backed by a 3-year warranty, this fire-rated slim downlight is ideal for multi-family housing, hotels, corridors, stairwells, commercial buildings, and code-restricted installations.

Technical Specifications

General

• Product Code: G-97024

• Item Description: S6/18W/SQ/LED/5CCT FR

• Fixture Type: Fire-Rated Slim LED Downlight

• Shape: Square

• Style: Trimmed

• Size: 6 Inch

• Finish: White

• Diffuser: Frosted

• Number of Lights: 1

Dimensions & Installation

• Cutout Size: 6.10"

• Outside Dimension (OD): 6.81"

• Fixture Height: 1.67"

• Mounting: Clip-in

• Clip Compatibility: Double 5/8" Sheetrock

Light Output

• Wattage: 18W

• Lumens: 1600

• CRI: >90

• Beam Angle: 100°

• Color Temperature: 5CCT Selectable

  • 2700K / 3000K / 3500K / 4100K / 5000K

Electrical

• Input Voltage: 120–277V

• Output Current: 430mA

• Dimming: Triac or 0–10V

Compliance & Ratings

• Fire Rating: 2 Hours

• Certifications: UL 263 & ASTM E119

• IC Rated: Yes

• Location Rating: Wet Location

• Listing: ETL Listed

• Warranty: 3 Years

Packaging Information

• Master Pack: 18 units

• Barcode (UPC): 024431970244
