3" Square Regress Gimbal LED Downlight | 800Lm | CCT Selectable | Goodlite G-20090/G-48363/64/65/69

Deliver anti-glare, high-efficiency directional lighting with the Saturn 3" Square Regress Gimbal LED Recessed Light. Designed with a clean white trimmed square frame, a regressed optic design, and a clear diffuser, this versatile 3-inch fixture provides superior visual comfort while allowing precise beam positioning via its 360° rotation and 30° tilt angle. Featuring a focused 40° default beam spread and an impressive 800-lumen output, it is ideal for residential, commercial, and multi-family accent or task lighting applications.

Equipped with 5-CCT Field Selectability, it allows instant color switching between 2700K, 3000K, 3500K, 4100K, and 5000K directly on-site. Operating at 8W with a high color rendering index (CRI >90), it delivers exceptional energy efficiency and true color accuracy. The fixture operates on a universal 120-277V AC input, features an FT6 plenum rating, and supports continuous dimming (100% to 5%) via Triac or 0-10V dimming protocols.

Engineered for safe and simple installation, the luminaire is IC-rated for direct contact with ceiling insulation and uses a spring-loaded clip-in mounting system into a standard 3.35" cutout. Certified ETL and Title 24 Listed, as well as Wet Location rated, it is suitable for indoor living areas, high-moisture spaces, covered outdoor soffits, and showers.

Key Features:

• 360° Rotation & 30° Tilt: Regressed gimbal design reduces visual glare while providing flexible aimability with a 40° default beam spread.

• 5-CCT Field Selectable: Easily customize color temperature between 2700K, 3000K, 3500K, 4100K, and 5000K.

• FT6 Plenum Rated & Universal Voltage: Built for commercial plenum ceilings operating on 120-277V AC with Triac or 0-10V dimming (100–5%).

• IC & Wet Location Rated: Safe for direct insulation contact and approved for high-humidity/wet environments.

• Clip-In Installation: Fast spring clip-in mounting requiring a 3.35" ceiling cutout with a 4.33" outside dimension profile.

• Energy Code Compliant: ETL listed, Title 24 compliant, CRI >90, and backed by a 3-year warranty.

Technical Specification Table

Packaging & Logistics Specifications

• Master Pack Quantity: 18 Pieces

• UPC / Barcode: 749354200901

• Included Accessories: Integrated LED Driver & Clip-In Spring Mechanism
