Flarion 4" Triple-Head Floating Gimbal LED Multiple Downlight – 36W, 5CCT Selectable, Adjustable (Black / White)

The Flarion 4-inch Triple-Head Floating Gimbal LED Downlight is a versatile architectural recessed lighting fixture designed for directional accent lighting and modern commercial installations. Featuring three independently adjustable floating gimbal heads, this fixture allows precise aiming of light to highlight architectural details, artwork, displays, or focal points.

Each LED head produces 1200 lumens, delivering a combined output of 3600 lumens, providing strong and efficient illumination suitable for retail environments, galleries, showrooms, hospitality spaces, offices, and modern residential interiors.

For enhanced flexibility, the fixture includes 5 selectable color temperatures (2700K, 3000K, 3500K, 4100K, and 5000K). This allows installers and lighting designers to adjust the ambiance depending on the application—from warm hospitality lighting to bright commercial environments. The high color rendering index (CRI >90) ensures accurate color reproduction, making it ideal for product displays and accent lighting.

Each gimbal head features 90° tilt and 360° rotation, providing complete directional control to precisely illuminate objects or architectural elements. The 40° beam angle creates a focused spotlight effect ideal for highlighting displays and visual focal points.

The fixture supports Triac and 0–10V dimming, allowing compatibility with both residential and commercial dimming systems for adjustable brightness control.

Designed for professional installations, the fixture includes a clip-in mounting system for quick and secure installation. It is also IC Rated and plenum rated (FT6), allowing installation in insulated ceilings and air-handling spaces.

With its wet location rating, the fixture can also be installed in bathrooms, covered outdoor ceilings, and other moisture-prone areas.

Certified ETL Listed and Title 24 compliant, and supported by a 3-year warranty, the Flarion 4" Triple-Head Floating Gimbal LED Downlight delivers a reliable and energy-efficient solution for directional architectural lighting.

Available Finishes

Technical Specifications

General Specifications

• Product Name: Flarion 4" Triple-Head Floating Gimbal LED Downlight

• Shape: Multiple

• Style: Trimmed

• Size: 4 Inch

• Finish Options: White / Black

• Diffuser: Clear

• Number of Lights: 3

Dimensions

• Cutout Size: 4.25" × 13.85"

• Outside Dimension (OD): 4.92" × 14.77"

• Height: 1.81"

Mounting

• Installation Type: Clip-in

Light Performance

• Total Wattage: 36W

• Lumens per Head: 1200 lm

• Total Lumens: 3600 lm

• CRI: >90

• Color Temperature: Selectable CCT

• CCT Options: 2700K / 3000K / 3500K / 4100K / 5000K

• Beam Angle: 40° (Default)

Adjustability

• Tilt Angle: 90°

• Rotation: 360°

Electrical Specifications

• Input Voltage: 120-277V

• Output Current: 900mA

• Plenum Rated: FT6

• Dimming: Triac or 0-10V Dimming Compatible

Compliance & Ratings

• Location Rating: Wet Location

• IC Rated: Yes

• Certification: ETL Listed, Title 24 Compliant

Packaging Information

• Master Pack: 12 Units

Warranty

• Warranty: 3 Years
