LED Explosion Proof Round Light | Class I Division II | 5000K | Dimmable | 100-277V | EPC C Series | 40, 60, 80, 100, 150, 200 & 250W

The C Series Luminaire is a high-performance, explosion-proof LED lighting solution engineered for hazardous and high-risk industrial environments. It provides reliable illumination in areas with flammable gases, vapors, dust, or fibers, making it ideal for a wide range of heavy-duty applications.

With its robust, impact-resistant construction and IP66/IK10 rating, this luminaire offers superior protection against water, dust, and mechanical stress. It delivers efficient, long-lasting performance in environments where safety and durability are critical.

Applications include:

• Petroleum production, refining, and storage facilities

• Oil and gas loading, pumping, and transportation terminals

• Paint and chemical processing plants

• Metal smelting, foundry, and fabrication industries

• Mining operations and tunnels

• Offshore platforms and marine vessels

• Aerospace clean rooms and manufacturing lines

• Food, flour, and distillation production facilities

• Electrical power generation and distribution stations

• Environments with high humidity, vapor, dust, or extreme temperatures

Key Features:

• Explosion-proof design suitable for hazardous Class I, II, III locations

• High durability for industrial and marine environments

• Suitable for spotlight, floodlight, tunnel, and wall pack configurations

• Resistant to vibration, corrosion, and impact

• Optimized for safety, reliability, and maintenance-free operation

• Available in multiple wattages and mounting options

⚙️ Ratings and Certifications

ATEX Certification:

• II2 G Ex db op is IIB T5/T6 Gb

• II2 D Ex op is tb IIIC T80/90°C Db IP66

IECEx Certification:

• Ex db op is IIB T5/T6 Gb

• Ex op is tb IIIC T80/90°C Db IP66

UL844 (North American) Certifications:

• Class I, Division 1, Groups C, D

• Class I, Division 2, Groups A, B, C, D

• Class II, Division 1, Groups E, F, G

• Class II, Division 2, Groups F, G

• Class III

Marine and Industrial Ratings:

• UL 1598, UL1598A, ABS Certified

• IP66 – Dust-tight and water-resistant

• IK10 – High impact resistance

🛡 Warranty

The C Series Luminaire includes a 5-year limited warranty (or as otherwise specified in contract terms), effective from the date of purchase.

Warranty terms:

• Requires invoice or shipment bill for claims.

• Covers manufacturer defects or faulty components.

• Installation, electricity, and labor costs are not covered.

• Misuse, improper installation, or wear from normal operation are excluded.

This luminaire combines safety, performance, and compliance to meet the demands of industrial and marine hazardous locations, making it a trusted choice for explosion-proof lighting systems worldwide.
