LED Exit & Emergency Light Thermoplastic Combo | 120/277V | CEM

The CEM LED Exit & Emergency Thermoplastic Combo is a reduced-profile, all-in-one life safety solution designed for maximum performance, efficiency, and code compliance. Combining a high-visibility LED exit sign with adjustable emergency lighting heads, this unit ensures safe evacuation during power outages while maintaining a sleek, modern appearance.

Equipped with ultra-bright white LED lamp heads, the CEM provides up to 30-ft center-to-center spacing with a 3-ft path of egress at a 10-ft mounting height, delivering superior light coverage for commercial environments. Each head operates at 1.5 watts, featuring an integrated lamp, reflector, and lens system for optimized performance.

The unit includes a bi-color LED indicator (green for normal operation, red for battery alert), simplifying maintenance and monitoring. A push-to-test switch and charge indicator ensure compliance with safety regulations, while the solid-state transfer switch guarantees automatic activation during power loss.

Powered by a 3.6V maintenance-free NiCd battery, the CEM delivers a minimum of 90 minutes of emergency illumination. Its dual voltage (120/277V) capability ensures flexible installation across various commercial applications.

Constructed from flame-retardant, high-impact thermoplastic, the CEM is built for durability and long-term use. Installation is simplified with an included mounting canopy for top or end mounting, plus a universal knockout pattern for wall mounting. The snap-out chevron indicators allow for easy directional customization.

With advanced features like self-diagnostics (SDT) and remote capacity (RC 2.5W), this unit offers enhanced functionality for demanding environments. Backed by a 5-year warranty on electronics and housing, the CEM provides dependable performance for offices, schools, warehouses, retail spaces, and healthcare facilities.

Key Features

• Low-profile LED exit sign with integrated emergency lighting

• Ultra-bright white adjustable LED lamp heads

• Up to 30-ft spacing with 3-ft egress path at 10-ft height

• 1.5W per head (3 LEDs x 0.5W) for efficient output

• Dual voltage: 120V / 277V

• Bi-color LED indicator (green/normal, red/battery alert)

• Push-to-test switch for compliance testing

• Maintenance-free 3.6V NiCd battery

• Minimum 90-minute emergency operation

• Automatic solid-state transfer switch

• Fully automatic 24-hour recharge system

• Durable, flame-retardant thermoplastic housing

• Snap-out chevron directional indicators

• Universal mounting: top, end, or wall

• Remote capacity: 2.5W

• Self-diagnostic feature (monthly, biannual, annual testing)

• UL listed for damp locations

• Meets UL924, NFPA 101, NEC, OSHA, and CEC Title 20

• 5-year warranty on electronics and housing

Technical Specifications

General Information

• Model: CEM

• Product Type: Exit Sign & Emergency Combo

• Housing: Injection-Molded Thermoplastic (5VA Flame Retardant)

• Finish Options: White or Black

• Design: Reduced Profile

Emergency Lighting

• Lamp Heads: 2 Adjustable LED Heads

• Output per Head: 1.5W (3 LEDs x 0.5W)

• Coverage: Up to 30-ft spacing

Electrical

• Input Voltage: 120/277V Dual Voltage

• Battery: 3.6V NiCd Rechargeable (maintenance-free)

• Emergency Operation: Minimum 90 minutes

• Charging Time: 24 hours

• Transfer Switch: Solid-State Automatic

• Indicator: Bi-color LED (Green/Red) with push-to-test

Mounting

• Mounting Options: Top, End, Wall

• Mounting Canopy: Included

• Back Plate: Universal K/O pattern

Compliance & Ratings

• UL Listed for Damp Locations (0°C – 50°C)

• UL924 Certified

• NFPA 101 Life Safety Code Compliant

• NEC & OSHA Compliant

• CEC Title 20 Certified
