EasyLED Dome Top Bollard Light | 2,477 Lumens Max | Wet Location | BOQ

Provide durable, energy-efficient walkway and perimeter illumination with the EasyLED Round Dome Top Bollard Light. Specially engineered to replace legacy HID lighting systems up to 70W Metal Halide (MH) or High-Pressure Sodium (HPS), this commercial-grade landscape luminaire significantly cuts energy consumption and maintenance demands. It is ideal for retail shopping centers, corporate parks, educational campuses, airports, public transit stops, and healthcare facility grounds.

Constructed from heavy-duty extruded aluminum, the housing features a classic domed top, flush mounting base with vandal-resistant screws, and an internal ballast tray for simplified maintenance. The fixture offers three distinct optical styles: a specially designed cone reflector (including Soft Shine low-glare options), internal louvers, or a clear prismatic borosilicate glass refractor, available in Type III and Type V light distributions. Lens options include clear UV-stabilized vandal-resistant polycarbonate or SoftLED LumaLens opal UV-stabilized polycarbonate for smooth, glare-free light diffusion.

Designed for long-term outdoor reliability, the housing is finished with textured architectural bronze or black powdercoat over a corrosion-inhibiting chromate conversion coating. Powered by a universal 120-277V or 347V (15W model) electronic driver ($PF > 0.90$, $THD < 20\%$), the bollard includes standard 0-10V continuous dimming (100%–10%) and 2kV internal surge protection. Every unit includes an anchor bolt mounting kit with 8" zinc-plated bolts, and can be customized with factory-installed microwave motion sensors, photocells, emergency battery backup, GFCI convenience outlets, and custom height cuts.

Key Features:

• 70W HID Equivalent Efficiency: System wattages of 11.3W, 17W, and 23.8W deliver 620 to 2,450 lumens, offering substantial energy savings over traditional 70W MH/HPS fixtures.

• Rugged Extruded Aluminum Construction: Domed top design with flush mounting base, vandal-resistant screws, and internal ballast tray for easy servicing.

• Versatile Optical Configurations: Available with a high-efficiency cone reflector, internal glare-control louvers, or clear prismatic borosilicate glass in Type III and Type V distributions.

• IP65 Wet Location Rated: ETL listed for wet locations (ANSI/UL 1598, 8750) with an IP65 sealed LED compartment and UV-stabilized polycarbonate or LumaLens opal diffuse lens.

• Universal Voltage & Flexible Controls: Operates on 120-277V or 347V with 0-10V dimming and 2kV surge protection; options include microwave motion sensors, battery backup, and GFCI outlets.

Technical Specification Table

Product Logic & Ordering Catalog Matrix

Packaging & Included Accessories

• Standard Included Components:

  • Round Dome Top Extruded Aluminum Bollard Assembly.

  • Internal Ballast Tray with IP65 Sealed LED Board and Driver Module.

  • Anchor Bolt Mounting Kit (includes 8" zinc-plated anchor bolts, nuts, and washers).

  • Vandal-resistant mounting base hardware.

  • Internal 2kV Surge Protection Module.

• Factory Options & Accessories:

  • Custom height cuts available upon request.

  • Emergency battery backup module.

  • Internal microwave motion sensor / photocell controls.

  • Convenience GFCI outlet receptacle.
