Square Flat-Top LED Bollards | 3,296 Lumens Max | 3-CCT Selectable | BOL-S-LKFS

Enhance outdoor perimeter security, pathway safety, and commercial landscape aesthetics with the BOL-S-LKFS Square Flat-Top LED Bollard Series. Engineered for demanding architectural, municipal, and commercial applications, this square flat-top bollard delivers high-efficacy, low-glare ground illumination across walkways, entry plazas, parking perimeters, and corporate campuses.

Featuring advanced field-selectable versatility, the fixture includes integrated switches for on-site Lumen/Wattage Selectability (producing between 1,702 and 3,296 nominal lumens at 125 to 148 lm/W) and 3-CCT Field Selectability (3000K Warm White, 4000K Neutral White, and 5000K Cool White).

Constructed with a heavy-duty die-cast aluminum housing and a UV-stabilized, high-impact polycarbonate lens, the luminaire is available in durable Black and Dark Bronze powder-coat finishes. Powered by a universal 120-277V AC driver with 0-10V dimming capabilities and 4kV surge protection, the system guarantees long-life operation (L70 > 163,000 hours). The fixture is cULus Listed for Wet Locations across extreme ambient temperatures (-40°C to 55°C), IP65 rated, DLC Premium Qualified, and backed by a 5-year warranty.

Key Features:

• Field Selectable CCT & Lumens: On-site adjustable color temperatures (3000K/4000K/5000K) and lumen outputs (1,702 to 3,296 LM).

• Exceptional Efficacy & Lifespan: Delivers up to 148 lm/W with L70 rated LED lifespan exceeding 163,000 hours.

• Commercial-Grade Build: Heavy-duty cast aluminum housing with high-impact polycarbonate lens in Black or Dark Bronze.

• 120-277V & 0-10V Dimming: Universal line voltage driver with standard 0-10V dimming and 4kV surge protection.

• Extreme Weather Rated: IP65 ingress protection and cULus wet location certified from -40°C to 55°C (-40°F to 131°F); DLC Premium qualified.

Technical Specification Table

Packaging & Logistics Specifications

• Application Fit: New Construction & Retrofit Commercial Landscape / Pathway

• Master Pack: Standard Commercial Single-Unit Packaging
