20 Amp Duplex Receptacle | Isolated Ground | 125V | 5-20R | Industrial Grade | Enerlites 62010

The ENERLITES 62010 Industrial Grade Isolated Ground Duplex Receptacle is engineered for demanding commercial, industrial, and healthcare environments where electrical noise reduction, grounding integrity, and long-term durability are critical. Rated for 20 Amps and 125 Volts (NEMA 5-20R), this heavy-duty receptacle is ideal for powering sensitive equipment in hospitals, laboratories, data rooms, and industrial facilities.

Featuring an isolated ground design, the 62010 helps reduce electromagnetic interference (EMI) and electrical noise by separating the equipment grounding conductor from the device mounting yoke. This makes it a reliable solution for installations requiring clean, stable power for sensitive electronics and medical equipment.

Constructed with a high-impact resistant thermoplastic body and cover, this receptacle is built to withstand the harsh conditions typically found in industrial applications. A brass grounding strap with a self-grounding clip ensures consistent grounding continuity, while dual insulated side barriers provide enhanced protection by covering the wire terminals—offering improved insulation and isolation during installation and operation.

The back-wired design allows for secure and efficient wiring, and break-off tabs support easy two-circuit conversion, increasing flexibility for split-circuit applications. Designed for use with 10–14 AWG copper conductors only, the ENERLITES 62010 ensures reliable electrical connections and code-compliant performance.

With a UL94 V-2 flammability rating, a wide operating temperature range, and UL Listing, this industrial grade isolated ground receptacle delivers dependable performance, safety, and longevity—backed by a 2-year limited warranty.

 Technical Specifications

• Brand: ENERLITES

• Model Number: 62010

• Device Type: Industrial Grade Isolated Ground Duplex Receptacle

• Amperage: 20 Amp

• Voltage: 125 VAC

• NEMA Configuration: 5-20R

• Grounding Type: Isolated Ground

• Wiring Method: Back wired

• Wire Range: 10–14 AWG copper only

• Grounding: Brass strap with self-grounding clip

• Construction Features:

  • Impact-resistant thermoplastic body and cover

  • Dual side terminal barriers for insulation and isolation

• Break-Off Tabs: Yes, for two-circuit conversion

• Flammability Rating: UL94, V-2

• Operating Temperature:

  • -104°F (-40°C) without impact

  • Up to 167°F (75°C) continuous

• Certifications: UL Listed

• Applications: Hospitals, laboratories, data centers, industrial and commercial facilities

• Warranty: 2-Year Limited Warranty
