15 Amp Decorator Duplex Receptacle | 125V | 5-15R | Residential Grade | Enerlites 61501
- SKU: 61501-W
- UPC: 883951214500
- Category: Decorator Receptacles, Enerlites
Certs:
The Enerlites 61501 is a Residential Grade 15A Decorator Style Self-Grounding Duplex Receptacle designed for safety, reliability, and long-term performance. Built with high-impact resistant polycarbonate thermoplastic, this outlet is durable, heat-resistant, and easy to install in both residential and light commercial settings.
Its self-grounding design includes an optional clip or green terminal screw for quick and secure grounding. The shallow body design maximizes wiring space, and the back and side wiring terminals allow for versatile installation using either solid or stranded copper wire.
This receptacle meets NEC Article 406.12 (2017) requirements and is UL listed, ensuring safe operation and code compliance in homes, offices, hotels, and other facilities requiring a 15-amp circuit.
Technical Specifications
| Specification | Detail |
|---|---|
| Model Number | 61501 |
| Type | Decorator Duplex Receptacle |
| Amperage | 15A |
| Voltage | 125V |
| Grounding | Self-Grounding |
| Design | Decorator Style |
| Wiring Type | Back and Side |
| Material | High-impact polycarbonate thermoplastic |
| Tamper-Resistant | No |
| Flammability Rating | UL94 V2 |
| Operating Temperature | -104ºF to 167ºF |
| Certifications | UL Listed, NEC 2017 Article 406.12 compliant |
| Warranty | 2 Years |
| Color Options | White, Ivory, Light Almond, Black, Gray |
Key Features
-
Durable thermoplastic construction ensures long service life and high impact resistance
-
Self-grounding clip or green terminal screw provides flexible grounding options
-
Shallow body design offers maximum space for wiring in compact boxes
-
Break-off tabs allow for quick two-circuit conversion
-
Back and side wiring terminals accept both solid and stranded wire
-
Removable yoke tabs for precise alignment during installation
-
Combination Slot/Phillips head screws simplify wiring connections
-
UL listed and NEC compliant for safety and code adherence
-
2-year warranty for quality assurance
Applications
-
Homes, apartments, and condominiums
-
Office buildings and hotels
-
Restaurants and commercial properties
-
New construction or remodeling projects
-
Areas requiring a 15A outlet for general-purpose use
