10 Inch Up-Down Outdoor Wall Sconce | 24W Max | 2.400Lm Max | 3-CCT Selectable | 120/277V

Enhance your exterior walls with the LR40345 10" Up-Down Outdoor Wall Sconce, finished in sleek black. Designed with a modern cylindrical wall profile, this LED fixture provides balanced up-and-down illumination, ideal for residential, commercial, and hospitality exteriors. Perfect for entryways, patios, walkways, and building facades, it combines aesthetic appeal with high-performance lighting.

Featuring CCT and wattage selectable technology, this wall sconce allows you to choose from 3000K, 4000K, or 5000K color temperatures and 15W, 20W, or 24W power levels, delivering 1500–2400 lumens for versatile outdoor lighting. Its 30° beam angle and CRI of 80 provide uniform, high-quality light suitable for accent, task, or ambient applications.

Operating on 120–277V with dual dimming capabilities (TRIAC @120V / 0–10V @120–277V), the LR40345 offers a 50,000-hour rated lifetime, 80 lm/W efficacy, and a 0.9 power factor. It performs reliably in temperatures ranging from –4°F to 113°F, with a low estimated yearly energy cost of $2.89. Each unit ships with complete UPC and master barcode information for efficient inventory management.

🔧 Technical Specifications

Physical Dimensions

• Size: 10.15"

• Length: 10.15"

• Width: 3.54"

• Depth: 6.10"

• Shape: Outdoor Wall Sconce

• Finish: Black

• MOL: 10.15"

Photometric & Electrical

• Lumen Output: 1500 / 2000 / 2400

• Beam Angle: 30°

• CRI: 80

• CCT Options: 3000K / 4000K / 5000K

• Power: 15W / 20W / 24W

• Voltage: 120–277V

• Rated Lifetime: 50,000 hours

• Lumen Efficacy: 80 lm/W

• Power Factor: 0.9

• Frequency: 50/60Hz

• Dimmable: TRIAC @120V / 0–10V @120–277V

• Operating Temperature: –4°F to 113°F

• Estimated Yearly Energy Cost: $2.89

Packaging

• UPC Barcode: 793888420144

• Master Barcode: 10793888420141

• Master Carton Dimensions: 14.84" L × 13.97" W × 11.81" H

• Master Carton Weight: 17.55 lbs

• Case Size: 6
