150W LED Indoor Electronic Rope Light Hardwire Drivers Non-Dimmable | Ribbon Lighting Series

150W LED Indoor Electronic Rope Light Hardwire Driver (Non-Dimmable) – Ribbon Lighting Series | 24V Constant Voltage Power Supply

Power up your LED lighting system with the 150W LED Indoor Hardwire Driver, part of the trusted Ribbon Lighting Series. Delivering a consistent 24V DC output with a maximum current of 6.5 amps, this non-dimmable power supply is engineered for high-efficiency, long-term performance in indoor lighting applications. It's ideal for commercial displays, signage, architectural lighting, and other demanding LED setups that require reliable and protected power delivery.

🔧 Key Features:

• High-Capacity 150W Output
  Supports large-scale lighting installations with a 24V output and 6.5A current for superior power delivery across long LED rope or strip runs.

• Efficient & Reliable Performance
  Delivers up to 89% energy efficiency, helping reduce energy costs while maintaining consistent brightness with minimal power loss.

• Universal AC Input with Selector Switch
  Supports a wide input voltage range of 85–264VAC, selectable via an onboard switch to accommodate global power standards at 50/60Hz.

• Built-In Safety Protections
  Integrated short circuit, overload, over voltage, and over temperature protections safeguard both the driver and connected LEDs.

• Silent Cooling with Free Air Convection
  Operates without a fan for quiet performance, ideal for residential and commercial indoor settings where noise is a concern.

• Visual Power Status Indicator
  Includes an LED power-on indicator for quick operational status checks during installation and maintenance.

• Engineered for Long-Term Durability
  Rigorously tested with 100% full load burn-in and 5G vibration testing to meet industrial-grade reliability requirements.

📐 Technical Specifications:

• Output Power: 150W

• Output Current: 0–6.5A

• Output Voltage: 24V DC

• Input Voltage Range: 85–264VAC (manual switch selectable)

• Setup Time: 500ms

• Rise Time: 30ms (230/115VAC)

• Hold-Up Time: 40ms (230VAC), 35ms (115VAC)

• Efficiency: 89%

• No Load Power Consumption: <0.5W

• Leakage Current: <0.75mA at 240VAC

• Cooling Method: Free air convection

• Operating Temperature: Up to 158°F (70°C)

✅ Certifications & Compliance:

• UL60950-1

• TUV EN60950-1

• EN60335-1

• EN61558-1 / 2-16

• CCC GB4943.1

• BSMI CNS14336-1

• EAC TP TC 004

• AS/NZS 60950.1 (CB certified)

🌐 Electromagnetic Compliance (EMC):

• EN55032 (CISPR32) Class B

• EN55014

• EN61000-3-2, -3

• GB/T 9254

• BSMI compliant

💡 Perfect For:

• LED rope and strip lighting (non-dimmable)

• Commercial retail displays

• Indoor signage and backlighting

• Architectural cove lighting

• Hospitality and under-cabinet lighting
