100W LED Indoor Electronic Rope Light Hardwire Drivers Non-Dimmable | Ribbon Lighting Series

100W LED Indoor Electronic Rope Light Hardwire Driver (Non-Dimmable) – Ribbon Lighting Series | 24V Power Supply

Power your indoor LED lighting systems with confidence using the 100W Indoor Electronic Hardwire Driver (Non-Dimmable) from the Ribbon Lighting Series. Designed to deliver 24V DC constant voltage output, this high-efficiency power supply supports up to 4.5A of current, making it ideal for medium to large-scale LED rope light installations. It’s engineered for safety, long life, and silent performance in residential, commercial, and industrial environments.

🔧 Key Features:

• 100W Output for Demanding Applications
  Provides a stable 24V DC output with up to 4.5 amps, suitable for powering LED rope lights, tape lights, and other low-voltage fixtures over long runs.

• Wide Input Voltage (85–264VAC)
  Compatible with global AC power sources, supporting both 115V and 230V systems at 50/60Hz for maximum flexibility in installation.

• Reliable, Non-Dimmable Performance
  Designed for consistent, full-power lighting where dimming is not required. Ideal for signage, backlighting, or task lighting applications.

• Built-In Protections
  Integrated short circuit, overload, and over-voltage protection safeguards connected lighting systems and extends product lifespan.

• Efficient & Silent Operation
  Uses natural air convection cooling (fanless design) for quiet, maintenance-free performance in enclosed or noise-sensitive spaces.

• LED Power Indicator
  Visual confirmation of operation with a built-in LED indicator, aiding installation and troubleshooting.

• Durability-Tested for Industrial Use
  Passed 5G vibration tests and 100% full load burn-in testing to ensure durability and dependable operation in various environments.

📐 Technical Specifications:

• Input Voltage: 85–264VAC (50/60Hz)

• AC Input Current: 1.9A at 115VAC, 1.2A at 230VAC

• Output Voltage: 24V DC

• Output Power: 100W

• Output Current Range: 0–4.5A

• Setup Time: 500ms

• Rise Time: 30ms (115/230VAC)

• Hold-Up Time: 55ms (230VAC), 10ms (115VAC) at full load

• Leakage Current: <0.75mA at 240VAC

• No Load Power Consumption: <0.3W

• Cooling: Free air convection (fanless)

• Operating Temperature: Up to 158°F (70°C)

• Isolation Resistance: 100M Ohms / 500VDC / 25°C / 70% RH

• Withstand Voltage:

  • Input to Output: 4KVAC

  • Input to Ground: 2KVAC

  • Output to Ground: 1.25KVAC

✅ Certifications & Safety Compliance:

• UL60950-1

• TUV EN60950-1

• EN60335-1

• EN61558-1, EN61558-2-16

• CCC GB4943.1

• BSMI CNS14336-1

• EAC TP TC 004

• AS/NZS 60950.1 (CB certified)

📡 EMC & Noise Standards:

• EN55032 (CISPR32) Class B

• EN55014

• EN61000-3-2, EN61000-3-3

• GB/T 9254

💡 Recommended Applications:

• Indoor LED rope and strip light installations

• Cabinet, shelving, and display lighting

• Architectural lighting systems

• Commercial signage or advertising backlights

• Home and retail lighting setups without dimming needs
