Give the gift of deluxe Color Temperature-Selectable lighting, perfect for any kitchen, living room, or bathroom. Adjust between 3000K, 4000K, or 5000K to achieve the perfect lighting temperature in any room.
4 Inch Round, Edge-Lit Recessed LED Downlight
4 Inch Square, Edge-Lit Recessed LED Downlight
Our Topaz Recessed LED Downlight Series offers a clean appearance coupled with simple, housing free installation. Eliminating the need for a J-box or recessed housing, the DLE fixture uses a plenum-rated cable connector to link the downlight module to the remote driver box and then pops into place with its spring loaded retention tabs for a secure fit. The ultra-thin fixture depth and off-board driver allow for a more flexible installation and increased lifetime with improved thermal management. With a micro-switch on the driver housing, this series offers the ability to adjust the CCT to 3000K, 4000K, or 5000K. Simplify your installations using a single fixture that can be adjusted on the fly with Select CCT.
Construction
• Cast aluminum housing routes heat away from electrical components
• Edge-Lit technology allows for extremely thin fixture depth
• Adjustable, spring loaded retention tabs ensure secure fixture retention
• Low profile micro-switch on driver housing for CCT selection
• Certified for direct contact with insulation
• Includes gasket to meet AirTight requirements
Optical System
• Precision engineered optical stack creates uniform light distribution that maximizes lumen output
Electrical
• Off-board driver minimizes installation height and maximizes fixture life through improved heat management
• Input voltage of 120VAC
• Dimmable to less than 5% with compatible leading edge (TRIAC) and trailing edge (ELV) dimmers
• LM-79 testing performed in accordance with IESNA standards
LED
• Dual emitter array enables CCT selection
• CCT Selectable at 3000K, 4000K, or 5000K
• Binned within 4-step MacAdams with duv <±0.003
• TM-21 Reported L70(9K) hours >36,000
• Utilizes high performing LEDs with 90+ CRI and an R9 > 50
Finish
• White powder coat finish standard
• Accessory color trims available in Black, Nickel and Oil-Rubbed Bronze
Mounting and Installation
• Spring loaded retention tabs allow for easy installation into ceilings up to 3/4” thick with no need for a recessed housing
• Off-board driver/junction box includes two 1/2” KOs, two 3/8” KOs and four-port poke-in connectors
• Included paper cutting template
• Accessory metal rough in template available
• Accessory extension power cables (2’ & 10’) available
• Suitable for wet locations
• Operating temperature of 0° to 120°F (-18°C to 49°C)
Warranty
• 5-year limited system warranty standard
• Warranty does not cover product failure due to power surge
