15 Amp Duplex Receptacle | 125V | Residential & Commercial Grade Outlet | White
| SKU(s) | 270W |
| UPC | 032664750830 |
| Color | White |
| Width | 0.69 in |
| Length | 1.31 in |
| Height | 4.19 in |
| Wire | #14-10 AWG |
 View Spec Sheet
|
The Eaton 270W residential grade duplex receptacle is a durable and versatile power solution designed for both residential and commercial applications. Rated at 15 amps and 125 volts, this standard-grade receptacle features a straight blade design and NEMA 5-15R configuration. Constructed with impact-resistant thermoplastic for the face and body, and equipped with brass contacts, it ensures long-lasting performance under demanding conditions.
The receptacle supports both side and push wiring methods for easy installation, accommodates #14–10 AWG conductors, and features a flush-mount design with screw-type connections. This UL and NOM certified device meets RoHS compliance standards and is part of Eaton’s core pack series, making it ideal for bulk residential or commercial electrical projects.
Key Specifications:
Catalog Number: 270W
UPC: 032664750830
Amperage Rating: 15A
Voltage Rating: 125V
NEMA Configuration: 5-15R
Poles/Wires: Two-pole, 3-wire
Wiring Method: Side and push
Material: Impact-resistant thermoplastic
Contact Material: Brass
Mounting: Flush
Connection Type: Screw
Allowable Wire Size: #14–10 AWG
Torque Rating: 14 lbf-in
Color: White
Certifications: UL, NOM, RoHS Compliant
Application: Residential and Commercial
$4.50 /each
| SKU(s) | 6352W-BU |
| UPC | 032664584084 |
| Color | White |
| Voltage | 125V |
| Width | 0.84 in |
| Length | 1.32 in |
| Height | 4.19 in |
| Wire | #14-10 AWG |
| Certs |
|
|
View Spec Sheet
|
$1.50 /each
| SKU(s) | BR20W |
| UPC | 032664750724 |
| Color | White |
| Width | 0.88 in |
| Length | 1.3 in |
| Height | 4.2 in |
| Wire | #14-10 AWG |
|
View Spec Sheet
|
Industrial Grade Isolated Ground Heavy Duty 15A Duplex Receptacle, 5-15R
